Product features
- Data capture and processing via PC (PC not included)
- Includes Connector kit for LN2 pressure container
- Requirements for the PC (or laptop): operating system Windows® 7, 8.1 or 10, a free serial interface (9-pole) and USB port
- Temperature range: +40°C to -180°C
- Freezing chamber 217 x 217 x 348 mm (W x D x H) for maximum 1080 x 0.25 ml or 0.5 ml straws per freeze cycle
- Chamber volume: 16.4 l, stainless steel, use of handling rack (Ref. 16821/5030) recommended
- Required space without PC and dewar vessel: 540 x 420 x 520 (820) mm
- Electrical connection: 230 V, 50/60 Hz
- LN2 inlet on backside, central part
Your benefits
- Programming of multistage freezing curves
- Variable start temperature
- Data recorded for every single freezing cycle
- Temperature curves as well as crystallization inside straws can be observed during the freezing process
- Compact design
- Easy operation
